More Than Clean Room Man LiftsMore Than A65CR Clean Room Lift

A65CR Clean Room Lift

A65CR
[
Clean Room Lifts
]

Compact and highly maneuverable, the A65CR is ideal for small footprint clean rooms with limited turning space.

Working Height
71 ft
21.64 m
Platform Height
65 ft
19.81 m
Platform Capacity
500 lbs
226.8 kg
Platform Size
60 × 36 in
1.5 × 0.9 m
Horizontal Reach
47 ft
14.32 m
Overall Width
7 ft 11 in
2.4 m
Stowed Height
10 ft
3.05 m
Stowed Length
29 ft 9 in
9.07 m
Tail Swing
4 ft 2 in
1.27 m
Inside Turning Radius
8 ft
2.44 m
Ground Clearance
7 in
0.18 m
Turret Rotation
360° Continuous
360° Continuous
Platform Rotation
180°
180°
Power Source
48 V
48 V
Wheelbase
10 ft
3.0

Specifications

Gallery

A65CR Clean Room Lift
A65CR Clean Room Lift
A65CR Clean Room Lift
A65CR Clean Room Lift
A65CR Clean Room Lift
A65CR Clean Room Lift
Document
Download Resources
Bailey Cranes product brochures and other informational documents are available for your growing business. If you need more information reach out today.
A65CR Brochure
Brochure
Downloading Updates
