CH Trax Compact Handler
CH Trax
[
Compact Handler Line
]
The CH Trax telehandler is intended for outdoor and uneven surfaces and provides all-terrain performance that disperses low ground contact pressure for those jobs that wheel-load pressure is critical. The rugged Trax gas engine can also be converted to LP with our conversion kit.
Specifications
Vertical Reach
24 ft
7.33 m
Horizontal Reach
16 ft
4.88 m
Lifting Capacity
5,000 lb
2,722 kg
Machine Weight
5,800 lb
2,630 kg
Drive System
Telescoping Tracks
Tracked Drive
Side Slope Operation
15°
15°
Grip System
Woods Power Grip
Woods Power Grip
Power Unit
Propane Kohler PCH740
Propane Engine
Gallery
Download Resources
Bailey Cranes product brochures and other informational documents are available for your growing business. If you need more information reach out today.
CH Trax Brochure
Brochure
Additional Attachments
CH 10 Omni Compact Handler
Working Height
32 ft
Lift Capacity
10,200 lbs
Machine Weight
10,000 lbs
Learn More
CH 6 Compact Handler
Working Height
24 ft
Lift Capacity
6,000 lbs
Machine Weight
5,500 lbs
Learn More
